Roper
3600 Series Pump
Quantity:
Heavy Duty Pumps
General purpose pumps for mixing, blending, recirculating, fixed and mobile transfer up to 468 GPM up to 125 PSI
These pumps operate smoothly and with equal efficiency in either direction of rotation. They effectively handle heavy, viscous materials such as asphalt, molasses, roofing compounds, and printing inks, as well as fuel oils, gasolines, and similar thin liquids.
Features
Quiet-Running Helical Gears:
- Heat treated cast-iron pumping gears are accurately machined for quiet, efficient operation and long life.
- The pumping gears are keyed to their shafts with a sliding fit and are easily replaced.
- Accurate machining ensures proper meshing and reduces friction and vibration
Precision-Ground Shafts:
- The steel shafts are induction hardened in the bearing and sealing areas and are precision ground to exacting standards for maximum life.
- Hardened stainless steel shafts available.
Long-Lasting Bearing Surfaces:
- Bearings are special wear-resistant, high-lead bronze. Iron and carbon bearings are available.
- Four heavy duty sleeve bearings provide positive support to pumping gears and ensure long, efficient service.
- Bearing grooves allow circulation of the liquid being pumped for lubrication & control of bearing temperature
- Outboard drive shaft bearing supports external radial loads and absorbs axial thrust loads.
Rugged Housings:
- Standard castings are cast iron.
- Precise manufacturing tolerances provide minimum clearances for maximum pumping efficiency.
- Large, hardened steel dowel pins ensure positive alignment between the faceplate, case, and backplate.
