Pulsarlube
Pulsarlube EXPL
60 Bar
The best operating pressure (60bar) among existing explosion proof single point automatic lubricator
IP65
IP65 – dust tight and protected against water jet
Global Explosion Proof Certificate
The Industry’s first highest explosion-proof certified lubricator designed for safe use in the area classified as danger zone
Service Pack
Substantial savings with the use of replaceable grease pouches and battery packs
The Pulsarlube EXPL is an electromechanical lubricator specifically engineered for use in environments where explosion-proof certified devices are required, ensuring safe operation in the presence of explosive gases or dust.
The Pulsarlube EXPL is the industry's first electromechanical automatic grease lubricator with the highest explosion-proof certification, making it safe for use in classified hazardous zones. It delivers exceptional performance with an industry-leading operating pressure of 60 bar, surpassing other explosion-proof single-point automatic lubricators. Additionally, it offers significant cost savings with its easily replaceable, economical service pack. Designed with an energy-limitation concept, the Pulsarlube EXPL features a non-sparking, explosion-proof structure that prevents electrical devices from igniting explosive gases, even under normal or certain abnormal conditions.
Specs
60ml / 120ml / 240ml / 480ml (pre-set)
- DC 4.5V Battery Pack (replaceable)
- Standard : Alkaline Battery
- Optional : Lithium Battery
30-60bar (435-870psi)
-15˚C ~ 50˚C (5°F ~ 122°F)
- 60ml : 1 ~ 12 month
- 120ml ~ 480ml : 1, 2, 3, 6, 9, 12 month
Max. 6m (20ft) with Ø6 tube
Lithium Battery : Max. 3m (10ft) with Ø6 tube (Up to 8 lube points)
10 Units/Case
ATEX, KCs, CE / Etc., IECEx, NEPSI, TS, ETL
